Home - Products - Vacuum Furnace - High pressure reactor for crystallization and catalysis KS-VF-MR250
It is microwave high pressure reactor suitable for microwave synthesis, microwave crystallization, microwave catalysis, microwave polymerization, microwave foaming, microwave high pressure reaction and other experimental research.
Technical Parameters
Features of microwave reactor:
1. Suitable for microwave synthesis, microwave crystallization, microwave catalysis, microwave polymerization, microwave foaming, microwave high pressure reaction and other experimental research.
2. Significantly shorten the reaction, crystallization and synthesis time. Reduce the reaction, crystallization, and synthesis temperature. No thermal inertia, easy to control the reaction progress.
Parameters of the components of the microwave reactor system:
(1) The outer kettle of the system is designed with 316 stainless steel to ensure the safety of all locking devices and basic components.
(2) The control adopts PLC+7-inch touch screen control, real-time storage of experimental data, real-time display of experimental curves and data, with data export function.
(3) Equipped with 1500w/2450Mhz magnetron, with uniform microwave heating performance and fast heating speed.
(4) The sample is quickly and completely digested under the maximum pressure of 10mpa and the maximum temperature of 300℃. When the pressure in the furnace chamber rises rapidly to reach a specific pressure or higher, the automatic exhaust device starts to operate to ensure safety.
(5) The lid of the kettle adopts a twist-and-open lid opening method, which is quick to open the kettle; the kettle body is cooled by cooling circulating water, which minimizes the experiment time.
(6) According to the capacity of different digestion tubes, 4~12 samples can be digested at the same time. The capacity of the digestion tube ranges from 5ml to 70ml.
(7) Gas regulation module: It can perform gas input/discharge at a preset time point. The amount of gas initially charged can be adjusted according to the user's required pressure value (nitrogen, maximum 60bar)
Technical Parameters:
| Name | Microwave reactor |
| Capacity volume | ≤250ml |
| Number of digestion tubes | 4-12 only |
| Digestion tube capacity | 5ml-70ml |
| Rotation speed of digestion tube | ≤1000 rpm |
| Microwave reactor material | External pressure-bearing 316L material + anti-corrosion PTFE liner |
| System operating temperature | ≤300℃ |
| System use pressure | ≤10mpa |
| Control System | Automatic reaction control, automatic ventilation and exhaust, touch screen operation, real-time display of experimental data and curves |
| Microwave parameters | 1500w/2450Mhz magnetron, with uniform microwave heating performance, fast heating speed |
| System size | 480mm*500mm*700mm |
