4.3-inch full-color touch screen operation, easy to use
Compact structure, convenient to use in the glovebox
Built-in help function, equipped with guide and quick start.
Technical Parameters
Product Features:
4.3-inch full-color touch screen operation, easy to use
Compact structure, convenient to use in the glovebox
Built-in help function, equipped with guide, quickstart
Provide manual up and down height adjustment for convenient position adjustment
The base is equipped with heating function, and the temperature is controllable, up to 200C
Technical Parameters:
| Model | KS-SP-DP100 |
| Operating speed | 0.1-600mm/min |
| Lifting stroke | 0- 100mm (other strokes can be customized) |
| Displacement accuracy | 0.01mm |
| Rated linear thrust | > 50N |
| Immersion time | 1 -9999.9s |
| Interval between repeated coatings | 1-9999.9s |
| Repeated coating times | 1-999 times |
| Chip selection size | ≤100*100*5 (mm)Can name and store 100 groups of coating progra ms |
| Heating temperature | room temperature~120"C (h eating type) |
| Dimensions | 227mm(W)*350mm(D)*41 6mm(H) |
