The 20 Ton Laboratory Hydraulic Pressing Machine has the advantages of small volume, high pressure and high precision of pressure control. It is applied to chemical industry, such as: scientific research, pharmaceutical, teaching, testing, catalysis and so on
Technical Parameters
The 20 Ton Laboratory Hydraulic Pressing Machine has the advantages of small volume, high pressure and high precision of pressure control. It is applied to chemical industry, such as: scientific research, pharmaceutical, teaching, testing, catalysis and so on.In addition, this product can also be used with Fourier infrared spectrometer.Fluorescence spectrometer supporting sample preparation, can replace similar imported products.
Technical Parameters:
| Model | KS-PCD-20S |
| Pressure range | 0-20.0 Ton |
| Pressurization method | Electric pressurization/manual pressurization |
| Workbench diameter | 105mm |
| Piston diameter | 95mm |
| Pressure meter display range | 0-40Mpa |
| Intensity conversion | Automatic conversion of die pressure |
| Max Lifting height of cylinder | 30mm (T) |
| Pressure stability | ≤1 Mpa/ 10 min |
| Column quantities | 4 |
| Column spacing | 80×150mm (M×N) |
| Dimension | 245×415×415mm(L×W×H) |
| Power supply | 220V, 50HZ/60HZ |
| Net weight | 58kg |
