Counterweight sliding loading system, the operation is more convenient and flexible, and can minimize sample damage
Technical Parameters
Features
●The operation panel is simple and intuitive.
● Closed transparent shield and safety switch provide protection for the operator.
● Counterweight sliding loading system, the operation is more convenient and flexible, and can minimize sample damage
● Closed-loop control cutting to prevent overloading of motors, circuits, etc.
● The sample cutting completion can be stopped automatically.
●The use of imported diamonds works best.
Technical Parameters:
| Model | KS-CS-150 |
| Name | Specifications |
| Cutting piece | Standard 150x12.7x0.43mm (6inch) |
| Cutting positioning accuracy | 0.01mm |
| Cooling device | Automatic circulation cooling of cutting fluid (cutting piece drives water circulation cooling of the sink) |
| Brushless DC Motor | Power: 550W Speed: 0-1650r/min |
| Display | LED digital display |
| Emergency brake device | Emergency stop switch |
| Power | AC220V 50HZ |
| Dimensions | 520 x 430 x 390 mm |
| weight | 33kg |
