Home - Products - Cutting Saw - Manual metal cutting and automatic cutting Metallographic machine KS-CS-6100D
It is suitable for cutting precision various materials with strong ability, high reliability, easy operation. The machine consists of machine body, electrical control tank, super cutting room, and cooling system, supporting more economical and convenient cutting models.
Technical Parameters
Application
It is suitable for cutting precision various materials with strong ability, high reliability, easy operation. The machine consists of machine body, electrical control tank, super cutting room, and cooling system, supporting more economical and convenient cutting models. Meanwhile the user can define cutting models. Meanwhile the user can define cutting speed and track. At the same time, this machine have following features, such as self-test, security. Running tips in order to improve the quality of cutting sample. It is one necessary equipment in laboratory of colleges, research institutes and factories.
Technical Parameters:
| Model | KS-CS-6100D |
| Input voltage | 380v/50HZ |
| Feed speed | 0.1-15mm/m |
| Spindle speed | 2200RPM |
| Cut-off wheel | Φ350×2.5×32mm |
| Cutting capacity(Max) | Φ100mm |
| Max Table Moving Distance | 145mm(Only Y axis for Auto&Manu) |
| Input power | 3.3kw |
| Cutting motor | 3kw |
| Dimensions | 960mm×855mm×735mm |
| Table Dimension | 330mm×280mm |
| Net weight | 285kg |
| optional | Cabinet / Transversal worktable (X axis) |
