KS-STX-2401 automatic diamond wire cutting machine is suitable for cutting materials with different hardness, such as ceramics, crystals, glass, metals, rocks, thermoelectric materials, infrared optical materials, composite materials and biomedical materials. It is mainly used for processing large-sized precious materials, and the cutting size can reach 24".
Technical Parameters
| product name | KS-STX-2401 Automatic Diamond Wire Cutting Machine |
| Product number | KS-STX-2401 |
| installation conditions | 1. This equipment is required to be used at an altitude of less than 1000m, a temperature of 25°C±15°C, and a humidity of 55%Rh±10%Rh. 2. Water: None. 3. Electricity: AC220V 50HZ. 4. Air: air source (0-1Mpa). 5. Working area size: 2200mm*1700mm*2600mm. 6. Ventilation device: Required. |
| The main parameters | 1. Power supply: 220V 50Hz 2. Machine power: <4100w 3. Spindle servo motor power: 2kw 4. Y, Z, R axis feed motor brand: Panasonic servo motor 5. Control system and method: PLC, touch screen ① Manual Control interface: Z-axis speed setting range: 1~150mm/min (only integer) Y-axis speed setting range: 1~500mm/min R-axis speed setting range: 1~200°/min ②Automatic control interface: cutting speed Setting range: 0.05～30mm/min Cutting times: 1-99 times Return speed: 1～150mm/min 6. Display method: digital display 7. Safety device: automatic stop when thread breaks, emergency stop switch 8. Total length of cutting line : ≤270m 9. Cutting wire diameter: ≤0.45mm 10. Cutting wire speed: adjustable within 0-8m/s 11. Z-axis stroke: ≤680mm 12. Y-axis stroke: ≤650mm 13. Y-axis advance Accuracy of indication value: 0.01mm 14. Z-axis feed speed: 1mm/min-150mm/min 15. Cutting speed: 0.05-30mm/min 16. Tensioning method: pneumatic tensioning, allowing the use of air pressure adjustment range 0.1-0.4 MPa 17. Adjustable range of guide wheel tangent distance: 900-530mm 18. Adjustable torque range of threader: 0-2.4Nm 19. Worktable size: 700mm×700mm 20. Worktable rotation angle: 0-360° 21. Worktable rotation positioning accuracy: ±0.1° 22. Cutting sample size: Ø600mm×650mm (max) 23. Worktable load: 600KG (max) |
| product specification | Size: 2082mm×1500mm×2481mm;Net weight: about 1600kg |
