Fully automatic control and manual switching
Extremely long cleaning times and long-lasting stability
Suitable for mass production of small parts
The preferred model for university research institutes
Technical Parameters
Model | KS-PL-2S | KS-PL-5S | KS-PL-10S | KS-PL-10SZ |
Cavity material quality | 316 stainless steel surface treatment | |||
Cavity size | F100×270Lmm | Φ150×270Lmm | 220 ×260×200mm L×W×H | |
Cavity capacity | 2L | 5L | 10L | |
Electrode plates | monolayer | double deck | ||
Form factor | 560×540×410mm L×W×H | 560×540×410mm L×W×H | 650 ×550×440mm L×W×H | |
Power frequency | 40KHz | |||
Power supply | 0-300W (continuously adjustable) | |||
flowmeter | High precision 2-way float flowmeter | |||
vacuometer | Pressure gauge (quantitative value display) | |||
Control the process | Fully automatic control and manual (PLC HMI) | |||
Cleaning time | 0- 9999S adjustable | |||
Vacuum level | 1-30pa | |||
Chamber temperature | <60℃ | |||
Supply voltage | 220V | |||
vacuum pump | 2XZ-2(speed 2L/S) | 2XZ-4(speed 4L/S) |
