Home - Products - Battery R and D Equipment - Battery Electrode Fabric Reel Slitter Slitting Machine KS-CDB-BES300
It is mainly used for the electrode sheets of lithium-ion batteries after coating, drying and rolling. It is divided into strips according to the width, length and other specifications of the battery design to form the electrode sheets that meet the shape required for the assembled battery, ensuring the smooth assembly of the subsequent battery. The cutting edges are neat and the dimensional accuracy is high.
Technical Parameters
Product Description:
It is mainly used
for the electrode sheets of lithium-ion batteries after coating, drying and
rolling. It is divided into strips according to the width, length and other
specifications of the battery design to form the electrode sheets that meet the
shape required for the assembled battery, ensuring the smooth assembly of the
subsequent battery. The cutting edges are neat and the dimensional accuracy is
high.
Product Features:
> Adjustable
guide device for feeding positioning;
> Electric
rolling and slitting method;
> Adjustable
meshing amount;
> The upper and
lower blades are at the same speed and synchronous transmission;
> Organic glass
protection device is configured at the hob for safe operation;
> Open hob
fixing method is convenient for hob disassembly;
> High slitting
accuracy and reliable operation.
> Simple operation, safe and reliable, beautiful appearance.
Technical
Parameters:
| Product model | KS-CDB-BES300 |
| Product name | Battery Electrode Fabric Reel Slitter Slitting Machine |
| Cutter type | Upper and lower circular knives for cutting |
| Cutter width | 20～300mm |
| Cut thickness | 80-300μm battery pole |
| Burr condition | ≤25μm |
| Cutter diameter | 85mm |
| Cutting speed | Max4m/min, adjustable speed |
| Power supply | AC220V/50Hz |
| Power | 200W |
| Dimensions | 850×920×400mm |
| Equipment weight | 79KG |
